RANSAC and other model fitting algorithms

Detailed Description

Collaboration diagram for RANSAC and other model fitting algorithms:

Classes

class  mrpt::math::ModelSearch
 Model search implementations: RANSAC and genetic algorithm. More...

class  mrpt::math::RANSAC_Template< NUMTYPE >
 A generic RANSAC implementation with models as matrices. More...


Typedefs

typedef RANSAC_Template< double > mrpt::math::RANSAC
 The default instance of RANSAC, for double type. More...


RANSAC detectors

template<typename NUMTYPE >
void mrpt::math::ransac_detect_3D_planes (const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &x, const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &y, const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &z, std::vector< std::pair< size_t, TPlane >> &out_detected_planes, const double threshold, const size_t min_inliers_for_valid_plane=10)
 Fit a number of 3-D planes to a given point cloud, automatically determining the number of existing planes by means of the provided threshold and minimum number of supporting inliers. More...

template<typename NUMTYPE >
void mrpt::math::ransac_detect_2D_lines (const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &x, const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &y, std::vector< std::pair< size_t, TLine2D >> &out_detected_lines, const double threshold, const size_t min_inliers_for_valid_line=5)
 Fit a number of 2-D lines to a given point cloud, automatically determining the number of existing lines by means of the provided threshold and minimum number of supporting inliers. More...

template<class POINTSMAP >
void mrpt::math::ransac_detect_3D_planes (const POINTSMAP *points_map, std::vector< std::pair< size_t, TPlane >> &out_detected_planes, const double threshold, const size_t min_inliers_for_valid_plane)
 A stub for ransac_detect_3D_planes() with the points given as a mrpt::maps::CPointsMap. More...


Typedef Documentation

◆ RANSAC

The default instance of RANSAC, for double type.

Definition at line 84 of file ransac.h.

Function Documentation

◆ ransac_detect_2D_lines()

template<typename NUMTYPE >
void mrpt::mrpt::math::ransac_detect_2D_lines ( const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &  x,
const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &  y,
std::vector< std::pair< size_t, TLine2D >> &  out_detected_lines,
const double  threshold,
const size_t  min_inliers_for_valid_line = 5
)

Fit a number of 2-D lines to a given point cloud, automatically determining the number of existing lines by means of the provided threshold and minimum number of supporting inliers.

Parameters
out_detected_linesThe output list of pairs: number of supporting inliers, detected line.
thresholdThe maximum distance between a point and a temptative line such as the point is considered an inlier.
min_inliers_for_valid_lineThe minimum number of supporting inliers to consider a line as valid.

Definition at line 280 of file ransac_applications.cpp.

References ASSERT_, mrpt::math::RANSAC_Template< NUMTYPE >::execute(), MRPT_END, and MRPT_START.

Here is the call graph for this function:

◆ ransac_detect_3D_planes() [1/2]

template<typename NUMTYPE >
void mrpt::math::ransac_detect_3D_planes ( const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &  x,
const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &  y,
const Eigen::Matrix< NUMTYPE, Eigen::Dynamic, 1 > &  z,
std::vector< std::pair< size_t, TPlane >> &  out_detected_planes,
const double  threshold,
const size_t  min_inliers_for_valid_plane = 10
)

Fit a number of 3-D planes to a given point cloud, automatically determining the number of existing planes by means of the provided threshold and minimum number of supporting inliers.

Parameters
out_detected_planesThe output list of pairs: number of supporting inliers, detected plane.
thresholdThe maximum distance between a point and a temptative plane such as the point is considered an inlier.
min_inliers_for_valid_planeThe minimum number of supporting inliers to consider a plane as valid.

Referenced by mrpt::math::ransac_detect_3D_planes().

Here is the caller graph for this function:

◆ ransac_detect_3D_planes() [2/2]

template<class POINTSMAP >
void mrpt::math::ransac_detect_3D_planes ( const POINTSMAP *  points_map,
std::vector< std::pair< size_t, TPlane >> &  out_detected_planes,
const double  threshold,
const size_t  min_inliers_for_valid_plane
)
inline

A stub for ransac_detect_3D_planes() with the points given as a mrpt::maps::CPointsMap.

Definition at line 67 of file ransac_applications.h.

References mrpt::math::ransac_detect_3D_planes().

Here is the call graph for this function:
